20mm Aluminium Round Tube for Water Cooling Towers， Precision Aluminum Tube，1050 Φ28mm，Customizable
| Place of Origin | Changzhou, Jiangsu , China |
|---|---|
| Brand Name | YUN NENG |
| Certification | ISO9001 ISO14001 ISO45001 |
| Model Number | 1050 |
| Minimum Order Quantity | 3 tons |
| Price | negotiation |
| Packaging Details | Standard export packaging |
| Delivery Time | 30 working days after received your down payment |
| Payment Terms | T/T |
| Supply Ability | 50,000 mt per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Length | 7000mm | Application | Air-conditioner, Refrigerator |
|---|---|---|---|
| Outside Diameter | 28mm | Size | Customized |
| Tensile Strength | 100MPa~135MPa | Wall Thickness | 1.5mm |
| Maximum Length | 18m | Non- Proportional Elongation Strength | ≥80MPa |
| Elongation After Break A50 | ≥5.00mm | Specification | According To The National Standards Or According To Customer Special Requirements For Customization |
| High Light | Cooling Tower 20mm Aluminium Round Tube,28mm 20mm Aluminium Round Tube,Precision Aluminum Tube 1050 |
||
Product Description
20mm Aluminium Round Tube for Water Cooling Towers, Precision Aluminum Tube,1050 Φ28mm,Customizable
Product Description:
We provide 1 series pure aluminum and 3003 series corrosion-resistant aluminum tubes.
Our company is capable of manufacturing thermal equipment air-cooled island tubes (aluminum heat exchanger tubes) with an outer diameter ranging from 15mm to 30mm, a wall thickness of 0.8mm to 2.0mm, and a length of 3M to 15m.
The company can customize non-standard heat exchange equipment aluminum tubes in accordance with customer requirements. The product is fabricated from silver aluminum alloy. The final form of the product is a straight pipe. Delivery can be made based on customer requests. The technical standard of the aluminum alloy clearly stipulates that the aluminum content of 1050 reaches 99.5%, which is a series commonly utilized in conventional industries.
Industrial pure aluminum possesses high plasticity, corrosion resistance, and good electrical and thermal conductivity, yet has low strength, is not subject to heat treatment, has poor cutting performance, and is acceptable for contact welding and gas welding.
Features:
We provide passivation and anti-corrosion treatment for both the inner and outer surfaces of aluminum tubes, as well as adding anti-corrosion coating suitable for use in large-scale heat exchange equipment.
Compared to standard aluminum, our alloy offers significantly improved corrosion resistance, withstanding up to 1000 hours in corrosion resistance tests. This results in a greatly extended product service life. Our company is capable of meeting a wide range of application requirements.
We can customize plates to meet specific needs regarding size, length, grade, thickness, and standards based on customer design and manufacturing needs. Additionally, we are committed to delivering products in a timely manner.
Technical Parameters:
| Main Size) | State | Outside Diameter /mm | Wall Thickness /mm | Length /m | Tensile Strength /MPa | Non-proportional Elongation Strength /MPa | Elongation After Break A50/mm | ||
| Model Number | |||||||||
| Main Size | |||||||||
| Series 1 | 1050 1060 1070 1050A | O | 20-32 | 0.8-2.0 | 5-15 | ≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 | |||||
| Series 3 | 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 | |||
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 | |||||
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 | |||||
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 | |||||
1050
| Model Name | Model Number | Outside Diameter /mm | Wall Thickness/mm | Maximum Length/m | Length/mm | Tensile Strength /MPa | Non-proportional Elongation Strength /MPa | Elongation After Break A50/mm |
| Main Size | Series 1 | 20-32 | 0.8-2.0 | 5000-15000 | ||||
| Series 3 | ||||||||
| Example | 1050 | 35 | 1.8 | 18 | 9000 | 100~135 | ≥80 | ≥5.00 |
| 21 | 1.0 | 7000 | ||||||
| 31 | 1.5 | 6000 | ||||||
| 32 | 1.9 | 8000 |
Applications:
power plant water cooling tower
surface condenser
large heat exchange equipment
condensator
evaporimeter
etc.
Support and Services:
The technical support and services for Air-conditioner and refrigerator tubes include:
Provide timely and accurate advice on product installation and maintenance.
Additionally, offer technical support and solutions for repair and maintenance.
Furthermore, ensure after-sales service and maintenance for all products is provided.
Offer professional advice and a timely response to customer inquiries.
Lastly, provide product training and technical advisory services.
FAQ:
Q1: What are the main products?
A1: We mainly produce Series 1 and 3 aluminum tubes in O, H14, and H12 state.
Q2: Do you provide samples?
A2: Yes, we provide samples for prototype testing. Shipping costs may apply based on shipping method and quantity.
Q3: Can I customize the product?
A3: Our products are customized according to customer requirements.
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
