Anti-Corrosion Treatment Power Plant Water Cooling Tower Aluminum Tubes 1050A H14
| Place of Origin | Changzhou China |
|---|---|
| Brand Name | Yun Neng |
| Certification | ISO9001 ISO14001 ISO45001 |
| Model Number | 1050A |
| Minimum Order Quantity | 3 tons |
| Price | negotiation |
| Packaging Details | Standard export packaging |
| Delivery Time | 30 working days after received your down payment |
| Payment Terms | T/T |
| Supply Ability | 50,000 mt per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Air-cooled Island Tube | Application | Large Peak Cooler, Surface Condenser,Air-conditioner, Refrigerator |
|---|---|---|---|
| Material | Aluminum Or Aluminum Alloy | Tensile Strength /MPa | 100-135 |
| Non-proportional Elongation Strength | ≥ 70Mpa | Elongation After Break | A50mm ≥ 5% |
| Outside Diameter/mm | 17Or Customized | Wall Thickness/mm | 1.3Or Customized |
| Color | Silver | ||
| High Light | Anti Corrosion 30mm aluminum tube,30mm aluminum tube 1070 D32,anti corrosion aluminum 32MM |
||
Product Description
Anti-Corrosion Treatment Power Plant Water Cooling Tower Aluminum Tubes H14
Product Description:
We provide series 1 of pure aluminum and 3003 anticorrosive aluminum aluminum pipes, which can produce air cooled island tubes (aluminum heat exchange tubes) for thermal equipment with outer diameter of 15mm to 30mm, wall thickness of 0.8mm to 2.0mm, and length of 3m to 15m. Or according to customer needs to customize non-standard specifications of heat exchange equipment aluminum pipe.
The product is made of aluminum alloy and looks like silver. The final status of the product is: straight tube. The internal and external surface of our aluminum pipe for passivation and anti-corrosion treatment, add anti-corrosion coating on the internal and external surface, with excellent corrosion resistance, can be suitable for the use of various media, such as: water, antifreeze, suitable for the use of large heat exchange equipment.
Features:
Use the special anticorrosive alloy, and add the anticorrosive coating on the internal and external surface. Compared with ordinary aluminum alloy, the corrosion resistance effect is greatly improved, and the corrosion resistance experiment is> 1000 hours, which can greatly improve the service life of the product. Using a special production process, the product has a high density and high efficient heat transfer performance. From the raw material to control the quality, the use of large tonnage extruder, hot extrusion cold pull production mode, can produce a variety of state performance. The product has high density, high heat transfer performance, high corrosion resistance , small tolerance range and better quality.
Applications:
power plant water cooling tower
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
Air-cooled Tower Tube
|
(Main Size)
Model Number |
State |
Outside Diameter /mm |
Wall Thickness /mm |
Length /m |
Tensile Strength /MPa | Non-proportional Elongation Strength /MPa | Elongation After Break A50/mm | ||
| Main Size | |||||||||
| Series 1 | 1050 1060 1070 1050A | O |
20-32
|
0.8-2.0 |
5-15 |
≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 | |||||
| Series 3 | 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 | |||
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 | |||||
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 | |||||
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 | |||||
1070
|
Model Name |
Model Number |
Outside Diameter /mm |
Wall Thickness/mm |
Maximum Length/m |
Length/mm | Tensile Strength /MPa |
Non- proportional Elongation Strength /MPa |
Elongation After Break A50/mm |
| Main Size |
Series 1, Series 3 |
20-32 | 0.8-2.0 | 5000-15000 | ||||
| Example | 1070 | 22 | 0.8 | 18 | 5635 |
100~135
|
≥80 | ≥5.00 |
| 26 | 1.0 | 6000 | ||||||
| 29 | 1.5 | 7000 | ||||||
| 32 | 1.8 | 9000 |
Support and Services:
We can provide technical support and services for the use of aluminum pipes, including technical guidance, production assistance, etc. Our experienced technicians can assist you with any problems your product may encounter. We also provide regular after-sales service to ensure that your products are always run at the highest efficiency. We are proud of our work and strive to provide the best customer service.
If you have any questions or concerns about the product or your use, please feel free to contact us. We will always give you the answers you need.
FAQ:
Q1: What kind of material alloy is the product?
A1: At present, it can produce 1 series industrial aluminum alloy, 3003 and 3103 aluminum manganese alloy, and 6 series aluminum alloy.
Q2: What state and performance of the aluminum pipe can be produced?
A2: can produce from hard state to soft state and interval performance products
Q3: Can I customize the product specifications and requirements?
A3: Different materials and products with different requirements can be customized according to the requirements
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
