Flat Plate 10mm Aluminium Tube Solar Collector Water Heater H14 D8 Flow Tube
| Place of Origin | Changzhou China |
|---|---|
| Brand Name | Yun Neng |
| Certification | ISO9001 ISO14001 ISO45001 |
| Model Number | 30588 |
| Minimum Order Quantity | 3 tons |
| Price | negotiation |
| Packaging Details | Standard export packaging |
| Delivery Time | 30 working days after received your down payment |
| Payment Terms | T/T |
| Supply Ability | 50,000 mt per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Flat Plate Solar Collector Aluminum Tube | Outside Diameter | 8mm Or Customized |
|---|---|---|---|
| Wall Thickness | 0.8-2.0mm Or Customized | Salt Spray Corrosion Test | > 1500 Hours |
| Yield Strength /Mpa | ≥110 | Elongation After Break A50mm | ≥5% |
| Tensile Strength/Mpa | 130-165 | State | H14 |
| Shape | Coil | ||
| High Light | Flat Plate 10mm Aluminium Tube,10mm Aluminium Tube H14,OD 8MM solar collector water heater |
||
Product Description
Flat Plate Solar Collector Water Heater H14 D8 Folw Tube Aluminum Tube
Product Description:
When compared to other solar collectors, flat plate collectors have a number of advantages:
(1) They are best suited for pressurized systems;
(2) They are best suited for double-cycle solar water heaters;
(3) They are best suited for the implementation of solar water heaters integrated with buildings;
(4) They have a long system life and require little maintenance;
(5) They can be used in solar heating systems to solve the system overheating issue more quickly.
Flat plate collectors have clear advantages over all-glass vacuum tube collectors in terms of system life, system maintenance, and other factors in the engineering of solar energy systems, split solar water heaters, and solar energy and building integration needs of the location.
Features:
Materials and specifications: a wide range of types, requirements, and sizes to meet the demands of real-world application scenarios.Corrosion resistance: We utilize specialized anti-corrosion technology to deal with the real use of some corrosive media and high temperature environments. using passivation, internal oil coating, or spraying zinc on the surface as well as other coping mechanisms.
Applications:
Flat-panel solar energy collector
solar collector
heat exchanger
Solar tube
Vacuum solar tube
Wall-mounted flat plate collector
Large solar energy collector
Technical Parameters:
| Product Name | Model Number (Material) | State | Salt Spray Corrosion Test >1500 hours Pressure Resistance ＞15 Mpa | ||||||
| Outside Diameter/mm | Thickness/mm | Tensile Strength/Mpa | Yield Strength /Mpa | Elongation | Length/mm | Shape | |||
Main Size Example | 30588 | H14 | 7-30 | 0.7-2.0 | 130-165 | ≥110 | ≥5% | Customized
| Coil |
| H12 | 115-150 | ≥75 | ＞12% | ||||||
| O | 95-130 | ＞60 | ≥30% | ||||||
H14, H12, O | 10 | 0.8-1.2
| Customized | ||||||
| 8 | |||||||||
| 12 | |||||||||
Can customize the production of a variety of specifications of the collector tubes.
| |||||||||
Support and Services:
Our team has professional technology and rich experience in production application, and we can provide technical support for the use of aluminum pipes to help customers solve technical production problems in the actual production application. Increase capacity.
We will make regular return visits to product use, listen to customer feedback in the first time, and make corresponding adjustments according to the actual situation.
Ensure sincere cooperation and common long-term development.
FAQ:
Q1: What kind of material alloy is the product?
A1: The product is made of our unique high-performance anti-corrosion aluminum alloy, whose performance is equal to the performance of the solar tube of Hyde Lu Aluminum industry.
Q2: What state and performance of the aluminum pipe can be produced?
A2: can produce from hard state to soft state and interval performance products
Q3: Can I customize the product specifications and requirements?
A3: Different specifications and states can be customized according to the requirements, such as fixed ruler straight pipe and coil pipe
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
