100Mpa 3003 Aluminum Tube Air To Water Heat Exchanger 3003 O Aluminum Alloy Pipe Condenser Tubes
| Place of Origin | Changzhou China |
|---|---|
| Brand Name | Yun Neng |
| Certification | ISO9001 ISO14001 ISO45001 |
| Model Number | 3003 |
| Minimum Order Quantity | 3 tons |
| Price | negotiation |
| Packaging Details | Standard export packaging |
| Delivery Time | 30 working days after received your down payment |
| Payment Terms | T/T |
| Supply Ability | 50,000 mt per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model Number | 3003 | Material | Aluminum Or Aluminum Alloy |
|---|---|---|---|
| State | O | Application | Heat Exchange Equipment，Air-conditioner, Refrigerator |
| Tensile Strength | 100Mpa-135Mpa | Non-proportional Elongation Strength MPa | ≥35 |
| Elongation After Break A50mm | ≥25.00 | Outside Diameter/mm | ≤20.00 |
| Wall Thickness/mm | ≤20.00 | Length | Customized |
| Shape | Coil | Specification | Refer To National Stamdars Or Customer Requirements |
| High Light | 100Mpa 3003 Aluminum Tube,Industrial freezer 3003 Aluminum Tube,100Mpa aluminum alloy round tube |
||
Product Description
Air To Water Heat Exchanger 3003 O Aluminum Alloy Pipe Condenser Tubes
Product Description:
Aluminum tube for heat exchangers is primarily produced in the 3 series, 1 series, 6 series, and 5 series aluminum alloys.
It is mostly utilized in the heat exchange tubes of different refrigeration and refrigeration equipment. It is commonly utilized in equipment including air conditioners, refrigerators, and warm air systems. Different state characteristics of the ruler straight pipe and coil pipe can be provided by the product. Our company's goods are made using a big extruder, cutting-edge production technology, specialized heat treatment technology, stringent process control, high precision, low leakage rate, and superior quality. And the density caused by the substance is great. Observe the processing specifications for back road use.
Features:
Cleanliness: To prevent the accumulation of pollutants and dirt that could reduce the effectiveness of heat transfer, condenser tubes must be kept smooth and clean on the inside.The interior wall is smooth, which prevents dirt accumulation and makes it simple to clean and maintain excellent heat conduction efficiency.
The benefits of aluminum over other tube materials include:
Aluminum is a good material option for applications that call for light weight because it is both lightweight and has good thermal conductivity.
Corrosion resistance: We utilize specialized anti-corrosion technology to deal with the real use of some corrosive media and high temperature environments. using passivation, internal oil coating, or spraying zinc on the surface as well as other coping mechanisms.
Techical Parameters:
Heat Exchanger Aluminum Tube
The main production specifications are listed as follows:
| Model Number | State | Wall Thickness mm | Tensile Strength MPa | Non-proportional Elongation Strength MPa | Elongation After Break A50mm |
| 1050 1060 1070 1050A | O | ≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 | |
| 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 |
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 | |
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 | |
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 |
Specifications can be customized according to customer requirements.
Applications:
Condensator
Evaporimeter
Air-conditioning
Icebox
Home freezer
Industrial freezer
Cold storage with cold exhaust pipe
Small warm wind
Lipstick shell
Eyebrow pen shell
Air conditioning connection pipe
Car water tank connecting pipe
Car air-conditioning connection pipe
Microchannel heat exchanger connecting tube
etc.
Production Process:
Coil pipe
Raw material procurement-inspection-cleaning-extrusion-coiling-heat treatment-flaw detection -forming-inspection-finished product packaging
Stright pipe
Raw material procurement-inspection-cleaning-extrusion-coiling-straightening-flaw detection-fine cutting-cleaning-heat treatment-inspection-finished product packaging
Support and Services:
We support and provide technical services for the use of aluminum pipes and assist customers to solve the production problems arising during the actual use process. Including the performance detection of aluminum pipe, technical analysis, the use of the back channel, aluminum pipe welding, aluminum pipe pipe, aluminum pipe bending, finished product leakage detection, etc., at the same time in the use of related problems, we will also assist customers to solve problems in the first time. And make corresponding adjustments according to the actual situation.
FAQ.:
Q1: What kind of material alloy is the product?
A1: Currently, there are 1 series, 3 series, and 6 series aluminum alloy.
Q2: What state and performance of the aluminum pipe can be produced?
A2: can produce from hard state to soft state and interval performance products
Q3: Can I customize the product specifications and requirements?
A3: Different specifications and states can be customized according to the requirements, such as fixed ruler straight pipe and coil pipe
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
