1070 D30 Aluminum Coil Tubing Aluminum Coil Power Plant Water Cooling Tower Aluminum Tube
| Place of Origin | From Jiangsu, China |
|---|---|
| Brand Name | Yun Neng |
| Certification | ISO9001 ISO14001 ISO45001 |
| Model Number | 1070 |
| Minimum Order Quantity | 3 tons |
| Price | negotiation |
| Packaging Details | Standard export packaging |
| Delivery Time | 30 working days after received your down payment |
| Payment Terms | T/T |
| Supply Ability | 50,000 mt per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Aluminum Coil Tubing | Application | Power Plant Water Cooling Tower, Surface Condenser,Air-conditioner, Refrigerator |
|---|---|---|---|
| Material | Aluminum Or Aluminum Alloy | Color | Silver |
| Tensile Strength /MPa | 100-135 | Non-proportional Elongation Strength | ≥ 80Mpa |
| Elongation After Break | A50mm ≥ 5% | Outside Diameter | 30mm |
| Wall Thickness/mm | 1.6mm | Length | 8000mm |
| Maximum Length | 18 Meters | Specification | According To The National Standards Or According To Customer Special Requirements For Customization |
| High Light | 100Mpa Aluminum Coil Tubing,D30 Aluminum Coil Tubing,135Mpa 1070 aluminum coil |
||
Product Description
Aluminum 1070 D30 Aluminum-coil Power Plant Water-cooling Tower Aluminum Tube
Product Description:
We Supply 1 series pure aluminum and 3003 series anticorrosive aluminum tubes. Our company can produce air-cooled island tubes (aluminum heat exchanger tubes) with outer diameter of 15mm ~ 30mm, wall thickness of 0.8 mm ~ 2.0 mm and length of 3M ~ 15m. Can also be customized according to customer needs of non-standard specifications of the heat exchange equipment aluminum tube.
The product is made of aluminum alloy. The final state of the product is: straight pipe. We passivate and anti-corrosion treatment on the inner and outer surfaces of aluminum tubes, and add anti-corrosion coating on the inner and outer surfaces, suitable for the use of large-scale heat exchange equipment.
Companies adhering to the hard technology, new materials, more efficient, more security purposes to better serve the major enterprises.
Features:
This product uses a special anti-corrosion alloy, in the inner surface and the outer surface of the anti-corrosion coating. Compared with the common aluminum alloy, the corrosion-resistant effect is obviously improved, the corrosion-resistant test time is more than 1000 hours, and the service life of the product is greatly increased. Our company adopts a special production process, products with high density, high efficiency of heat transfer performance. From the point of view of raw material quality control, the use of large-tonnage extruder, hot extrusion cold mode of production, can produce a variety of state performance. The product has the characteristics of high density, good heat transfer performance, good corrosion resistance, small tolerance and good quality.
The company always adhere to scientific and technological innovation, deep cultivation of industrial cutting-edge technology, and strive to industry customers and partners continue to enable, win-win.
Applications:
Power plant water cooling tower
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
Aluminum Coil Tubing
| (Main Size) | State | Outside Diameter /mm | Wall Thickness /mm | Length /m | Tensile Strength /MPa | Non-proportional Elongation Strength /MPa | Elongation After Break A50/mm | ||
| Model Number | |||||||||
| Main Size | |||||||||
| Series 1 | 1050 1060 1070 1050A | O | 20-32 | 0.8-2.0 | 5-15 | ≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 | |||||
| Series 3 | 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 | |||
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 | |||||
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 | |||||
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 | |||||
Support and Services:
We can provide technical support and services for the use of aluminum pipes, including technical guidance, production assistance, etc. Our experienced technicians can assist you with any problems your product may encounter. We also provide regular after-sales service to ensure that your products are always run at the highest efficiency. We are proud of our work and strive to provide the best customer service.
If you have any questions or concerns about the product or your use, please feel free to contact us. We will always give you the answers you need.
FAQ:
Q1: What kind of material alloy is the product?
A1: At present, it can produce 1 series industrial aluminum alloy, 3003 and 3103 aluminum manganese alloy, and 6 series aluminum alloy.
Q2: What state and performance of the aluminum pipe can be produced?
A2: can produce from hard state to soft state and interval performance products
Q3: Can I customize the product specifications and requirements?
A3: Different materials and products with different requirements can be customized according to the requirements
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
