1050A H12 D23.5mm WT1.45mm Round Aluminum Tube Corrosion Resistant Power Station
| Place of Origin | Changzhou China |
|---|---|
| Brand Name | Yun Neng |
| Certification | ISO9001 ISO14001 ISO45001 |
| Model Number | 1050A |
| Minimum Order Quantity | 3 tons |
| Price | negotiation |
| Packaging Details | Standard export packaging |
| Delivery Time | 30 working days after received your down payment |
| Payment Terms | T/T |
| Supply Ability | 50,000 mt per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Power Plant Air Cooling Tube | Application | Large Peak Cooler, Surface Condenser,Air-conditioner, Refrigerator |
|---|---|---|---|
| Material | Aluminum 1050A | Tensile Strength /MPa | 115-150 |
| Non-proportional Elongation Strength | ≥ 75Mpa | Elongation After Break | A50mm ≥ 14% |
| Outside Diameter/mm | 23.5 ± 0.28 | Wall Thickness/mm | 1.45± 0.28 |
| Weight (g/m) | 260 | Maximum Length/m | 15 |
| High Light | 1050A Round Aluminum Tube,Power Plant Air Cooling Aluminum Tube |
||
Product Description
1050A H12 D23.5mm WT1.45mm Round Aluminum Tube Corrosion-resistant Power Station
Product Description:
Essential for large power plants: our large heat exchange equipment subtly disposes of waste heat into the air, ensuring a smooth operation for our power generating gear.
http://mao.ecer.com/test/al-tubes.com/cases/power-plant-air-cooling-tube-product-pamphlet-15462.html
Crafted from pure aluminum, with an added dash of iron for reinforcement, 1050a possesses notable formability and processibility, admirable corrosion resistance, superior welding capabilities, and robust electrical conductivity. Often chosen for its utility in low strength applications, 1050a is a versatile metal.
Features:
Aluminium Extruded Tubes - Notes on Strength and Cost
While it may veer slightly softer in structure and strength compared with seamless tubing, extruded aluminium possesses a considerable edge when it comes to budget savings thanks to its increased productivity and lower production intricacy.
Its outstanding processing versatility also boosts its longitudinal (extrusion direction) mechanical prowess beyond many comparable counterparts.
Applications:
Large peak cooler
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
Industrial pure aluminum are characterized by high plasticity, corrosion resistance, good electrical and thermal conductivity, but low strength, can not be strengthened by heat treatment, cuttability is not good; can accept contact welding . Gas welding.
| 1- Appearance | Aluminium tubes without defect, without blow on its surface, without scratches, without pollution like grease or oil. |
| 2- Alloy Grade | 1050A |
|
3- Composition of alloy (%) Fe Mg Mn Ti Al Autres (others) |
0.40 0.05 0.05 0.05 99.50 0.05
|
|
Model Name |
Model Number |
Outside Diameter /mm |
Wall Thickness/mm |
Maximum Length/m |
Length/mm |
Tensile Strength /MPa |
Non- proportional Elongation Strength /MPa |
Elongation After Break A50/mm |
|
Main Size |
Series 1, Series 3 |
20-32 |
0.8-2.0 |
|
5000-15000 |
|
|
|
|
Example |
1050A |
28 |
1.0 |
18 |
7969 |
100~135
|
≥80 |
≥5.00 |
|
25 |
0.9 |
6959 |
||||||
|
23 |
1.5 |
9365 |
||||||
|
32 |
1.3 |
12266 |
H12 -- tensile strength value corresponds to the intermediate value between the annealed state O and the 1/2 hard state, called the 1/4 hard state.
Main Product:
How to order:
You can then download a form from this website and fill it out with basic details.
Send it to the provided e-mail address, and our engineers will price you based on the technical specifications.
http://mao.ecer.com/test/al-tubes.com/cases/how-to-order-15643.html
Alternatively, you can download the Technical Data Requirements Sheet directly.
Yuneng Product Requirements Table.docx
