High-performance 1070 D30 Aluminum Coil Tubing for Custom-made Heat Exchanger
| Place of Origin | From Jiangsu, China |
|---|---|
| Brand Name | Yun Neng |
| Certification | ISO9001 ISO14001 ISO45001 |
| Model Number | 1070 |
| Minimum Order Quantity | 3 tons |
| Price | negotiation |
| Packaging Details | Standard export packaging |
| Delivery Time | 30 working days after received your down payment |
| Payment Terms | T/T |
| Supply Ability | 50,000 mt per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Aluminum Coil Tubing | Application | Power Plant Water Cooling Tower, Surface Condenser,Air-conditioner, Refrigerator |
|---|---|---|---|
| Material | Aluminum Or Aluminum Alloy | Color | Silver |
| Tensile Strength /MPa | 100-135 | Non-proportional Elongation Strength | ≥ 80Mpa |
| Elongation After Break | A50mm ≥ 5% | Outside Diameter | 30mm |
| Wall Thickness/mm | 1.6mm | Length | 8000mm |
| Maximum Length | 18 Meters | Specification | According To The National Standards Or According To Customer Special Requirements For Customization |
| High Light | High-performance Aluminum Coil Tubing,Heat Exchanger Aluminum Coil Tubing,Custom-made Aluminum Coil Tubing |
||
Product Description
High-performance 1070 D30 Aluminum Coil Tubing for Custom-made Heat Exchanger
Product Description:
We offer 1 series pure aluminum tubes and 3003 series anticorrosive aluminum tubes. Our company produces air-cooled island tubes (aluminum heat exchanger tubes) with outer diameters of 15mm ~ 30mm, wall thicknesses of 0.8mm ~ 2.0mm, and lengths of 3M ~ 15m. Can also be tailored to meet the needs of customers with non-standard specifications for heat exchange equipment aluminum tubes.
The product is constructed from aluminum alloy. The final stage of the product is straight pipe. We passivate and apply an anti-corrosion treatment to the inner and outer surfaces of aluminum tubes, as well as an anti-corrosion coating, making them appropriate for use with large-scale heat exchange equipment.
Companies adhere to the hard technology, new materials, more efficient, and security purposes to better serve the major enterprises.
Features:
This product uses a specific anti-corrosion alloy on both the inner and exterior surfaces of the anti-corrosion coating. Compared to the common aluminum alloy, the corrosion-resistant effect is clearly improved, the corrosion-resistant test time is more than 1000 hours, and the product's service life is substantially increased. Our company uses a specific manufacturing process to produce items with high density and high heat transfer efficiency. In terms of raw material quality control, the employment of a large-tonnage extruder, hot extrusion, and cold mode of production can provide a wide range of state performance. The product's qualities include high density, good heat transfer performance, corrosion resistance, small tolerance, and high quality.
The organization is continuously committed to scientific and technology innovation, deep cultivation of industrial cutting-edge technology, and strive to industry customers and partners continue to enable, win-win.
Applications:
Power plant water cooling tower
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
Aluminum Coil Tubing
| (Main Size) | State | Outside Diameter /mm | Wall Thickness /mm | Length /m | Tensile Strength /MPa | Non-proportional Elongation Strength /MPa | Elongation After Break A50/mm | ||
| Model Number | |||||||||
| Main Size | |||||||||
| Series 1 | 1050 1060 1070 1050A | O | 20-32 | 0.8-2.0 | 5-15 | ≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 | |||||
| Series 3 | 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 | |||
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 | |||||
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 | |||||
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 | |||||
Support and Services:
We can provide technical support and services for the use of aluminum pipes, including technical guidance, production assistance, etc. Our experienced technicians can assist you with any problems your product may encounter. We also provide regular after-sales service to ensure that your products are always run at the highest efficiency. We are proud of our work and strive to provide the best customer service.
If you have any questions or concerns about the product or your use, please feel free to contact us. We will always give you the answers you need.
FAQ:
Q1: What kind of material alloy is the product?
A1: At present, it can produce 1 series industrial aluminum alloy, 3003 and 3103 aluminum manganese alloy, and 6 series aluminum alloy.
Q2: What state and performance of the aluminum pipe can be produced?
A2: can produce from hard state to soft state and interval performance products
Q3: Can I customize the product specifications and requirements?
A3: Different materials and products with different requirements can be customized according to the requirements
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
